领先同行Renesas active crystal oscillator，全球半导体解决方案供应商瑞萨电子(TSE:6723)今日宣布,推出一款全新汽车级智能功率器件(IPD)，该器件可安全、灵活地控制车辆内的配电,满足新一代电子/电子(电气/电子)架构的要求。新型RAJ2810024H12HPD采用小型至-252-7封装,与传统的至-263封装产品相比,安装面积减少约40%。此外,新OSC晶振器件的先进电流检测功能可实现对过流等异常电流的高精度检测。由于全新IPD即使在低负载时也能检测异常电流,因而允许工程师设计高度安全和精确的电源控制系统,甚至可以检测到最细微的异常情况。
瑞萨电子推出全新汽车级智能功率器件,可在新一代E E架构中实现安全、灵活的配电
瑞萨电子汽车模拟应用特定业务部副总裁大道昭表示:"推出采用瑞萨全新功率金属氧化物半导体场效应晶体管工艺的新一代汽车IPD，我们感到非常兴奋。瑞萨将继续致力于IPD和石英晶体振荡器的开发,提升电源系统的安全性和可靠性,并与我们的微控制器一起构建系统级解决方案,推动用户的系统开发。"
随着E/E架构不断发展,全新IPD的推出满足了日益增长的市场需求。在传统的分布式E/E架构中,来自电池的电能通过机械继电器和熔断器组成的电箱,经由长而粗的线束分配给各个电子控制单元(电子控制单元).与机械继电器相比，IPD的寿命更长且免于维护,因而可放置在车辆的任何位置。随着汽车行业向集中式或分区式E/E架构演进，IPD由于采用更短、更细的线束,正成为构建高效、灵活电源网络的理想选择。因此,瑞萨的IPD和时钟晶体振荡器器件特别为配电控制打造了一款更有效、更安全、更小巧的解决方案。领先同行Renesas active crystal oscillator.
全新IPD(RAJ2810024H12HPD)的关键特性
- 单通道高端IPD
- 小型至-252-7封装(6.10毫米x 6.50mm毫米:不包括引脚)
- 25摄氏度时低导通电阻(罗恩)为2.3mΩ(典型值)
- 在低负载情况下实现高精度电流检测
- 内置电荷泵
- 负载电流感测的自诊断反馈
- 负载短路、过热检测、感测电流输出,和GND开路保护等保护功能
- 支持3.3V/5V逻辑接口
- 低待机电流
- 具有自启动功能的电池反接保护
- 符合AEC-Q100和《关于限制在电子电气设备中使用某些有害成分的指令》汽车标准
-
"电子保险丝配电箱"解决方案Mfr Part # Mfr Description Series Frequency Output Voltage - Supply XAH335025.000000I Renesas晶振 XTAL OSC XO 25.0000MHZ LVCMOS XAH 25 MHz LVCMOS 3.3V XAH335006.005284I Renesas晶振 XTAL OSC XO 6.005284MHZ LVCMOS XAH 6.005284 MHz LVCMOS 3.3V XAH335006.005284K Renesas晶振 XTAL OSC XO 6.005284MHZ LVCMOS XAH 6.005284 MHz LVCMOS 3.3V XLH735032.000000X Renesas晶振 XTAL OSC XO 32.0000MHZ HCMOS SMD XPRESSOFXO-HC73 32 MHz HCMOS 3.3V XLH335012.288000I Renesas晶振 XTAL OSC XO 12.2880MHZ HCMOS SMD XPRESSOFXO-HC33 12.288 MHz HCMOS 3.3V XLH535125.000000I Renesas晶振 XTAL OSC XO 125.0000MHZ HCMOS XPRESSOFXO-HC53 125 MHz HCMOS 3.3V XLH730080.000000I Renesas晶振 XTAL OSC XO 80.0000MHZ HCMOS SMD XPRESSOFXO-HC73 80 MHz HCMOS 3.3V XLH536032.000000I Renesas晶振 XTAL OSC XO 32.0000MHZ HCMOS SMD XPRESSOFXO-HC53 32 MHz HCMOS 3.3V XLH736033.000000I Renesas晶振 XTAL OSC XO 33.0000MHZ HCMOS SMD XPRESSOFXO-HC73 33 MHz HCMOS 3.3V XLH736008.192000I Renesas晶振 XTAL OSC XO 8.1920MHZ HCMOS SMD XPRESSOFXO-HC73 8.192 MHz HCMOS 3.3V XLL536200.000000I Renesas晶振 XTAL OSC XO 200.0000MHZ LVDS SMD XPRESSOFXO-LC53 200 MHz LVDS 3.3V XLL535100.000000I Renesas晶振 XTAL OSC XO 100.0000MHZ LVDS SMD XPRESSOFXO-LC53 100 MHz LVDS 3.3V XLL735200.000000I Renesas晶振 XTAL OSC XO 200.0000MHZ LVDS SMD XPRESSOFXO-LC73 200 MHz LVDS 3.3V XLL525200.000000I Renesas晶振 XTAL OSC XO 200.0000MHZ LVDS SMD XPRESSOFXO-LC52 200 MHz LVDS 2.5V XLL725200.000000I Renesas晶振 XTAL OSC XO 200.0000MHZ LVDS SMD XPRESSOFXO-LC72 200 MHz LVDS 2.5V XLL726250.000000I Renesas晶振 XTAL OSC XO 250.0000MHZ LVDS SMD XPRESSOFXO-LC72 250 MHz LVDS 2.5V XLL736156.250000I Renesas晶振 XTAL OSC XO 156.2500MHZ LVDS SMD XPRESSOFXO-LC73 156.25 MHz LVDS 3.3V XLL528200.000000X Renesas晶振 XTAL OSC XO 200.0000MHZ LVDS SMD XPRESSOFXO-LC52 200 MHz LVDS 2.5V XFP236156.250000I Renesas晶振 XTAL OSC XO 156.2500MHZ LVPECL XFP 156.25 MHz LVPECL 3.3V XPC736156.250000I Renesas晶振 XTAL OSC XO 156.2500MHZ CML SMD XPC 156.25 MHz CML 3.3V XPP736156.250000I Renesas晶振 0156.250000MHZ 3.3VDC LVPECL 705 XPP 156.25 MHz LVPECL 3.3V XPP736312.500000I Renesas晶振 0312.500000MHZ 3.3VDC LVPECL 705 XPP 312.5 MHz LVPECL 3.3V XLH735050.000000X Renesas晶振 XTAL OSC XO 50.0000MHZ HCMOS SMD XPRESSOFXO-HC73 50 MHz HCMOS 3.3V XLH735001.000000X Renesas晶振 XTAL OSC XO 1.0000MHZ HCMOS SMD XPRESSOFXO-HC73 1 MHz HCMOS 3.3V XLH536040.000000I Renesas晶振 XTAL OSC XO 40.0000MHZ HCMOS SMD XPRESSOFXO-HC53 40 MHz HCMOS 3.3V XLH536012.000000I Renesas晶振 XTAL OSC XO 12.0000MHZ HCMOS SMD XPRESSOFXO-HC53 12 MHz HCMOS 3.3V XLH536027.000000I Renesas晶振 XTAL OSC XO 27.0000MHZ HCMOS SMD XPRESSOFXO-HC53 27 MHz HCMOS 3.3V XLH536048.000000I Renesas晶振 XTAL OSC XO 48.0000MHZ HCMOS SMD XPRESSOFXO-HC53 48 MHz HCMOS 3.3V XLH736010.000000I Renesas晶振 XTAL OSC XO 10.0000MHZ HCMOS SMD XPRESSOFXO-HC73 10 MHz HCMOS 3.3V XLH736024.000000I Renesas晶振 XTAL OSC XO 24.0000MHZ HCMOS SMD XPRESSOFXO-HC73 24 MHz HCMOS 3.3V XLH736033.333000I Renesas晶振 XTAL OSC XO 33.3330MHZ HCMOS SMD XPRESSOFXO-HC73 33.333 MHz HCMOS 3.3V XLH736050.000000I Renesas晶振 XTAL OSC XO 50.0000MHZ HCMOS SMD XPRESSOFXO-HC73 50 MHz HCMOS 3.3V XLH736001.000000I Renesas晶振 XTAL OSC XO 1.0000MHZ HCMOS SMD XPRESSOFXO-HC73 1 MHz HCMOS 3.3V XLH736040.000000I Renesas晶振 XTAL OSC XO 40.0000MHZ HCMOS SMD XL 40 MHz HCMOS 3.3V XLH536008.000000I Renesas晶振 XTAL OSC XO 8.0000MHZ HCMOS SMD XPRESSOFXO-HC53 8 MHz HCMOS 3.3V XLH736125.000000I Renesas晶振 XTAL OSC XO 125.0000MHZ HCMOS XPRESSOFXO-HC73 125 MHz HCMOS 3.3V XLH536028.636360I Renesas晶振 XTAL OSC XO 28.63636MHZ HCMOS XPRESSOFXO-HC53 28.63636 MHz HCMOS 3.3V XLH330012.000000I Renesas晶振 XTAL OSC XO 12.0000MHZ HCMOS SMD XL 12 MHz HCMOS 3.3V XLH736200.000000I Renesas晶振 XTAL OSC XO 200.0000MHZ HCMOS XPRESSOFXO-HC73 200 MHz HCMOS 3.3V XLH536125.000000I Renesas晶振 XTAL OSC XO 125.0000MHZ HCMOS XPRESSOFXO-HC53 125 MHz HCMOS 3.3V XLH536012.288000I Renesas晶振 XTAL OSC XO 12.2880MHZ HCMOS SMD XPRESSOFXO-HC53 12.288 MHz HCMOS 3.3V XLL735125.000000I Renesas晶振 XTAL OSC XO 125.0000MHZ LVDS SMD XPRESSOFXO-LC73 125 MHz LVDS 3.3V XLL335125.000000I Renesas晶振 XTAL OSC XO 125.0000MHZ LVDS SMD XL 125 MHz LVDS 3.3V XUL516100.000000I Renesas晶振 CLCC 5.00X3.20X1.10 MM, 2.54MM P XU 100 MHz LVDS 1.8V XUN535100.000000I Renesas晶振 MULTIMKT-TIMING XU 100 MHz HCSL 3.3V XUL536100.000000I Renesas晶振 MULTIMKT-TIMING XU 100 MHz LVDS 3.3V XUL536125.000000I Renesas晶振 MULTIMKT-TIMING XU 125 MHz LVDS 3.3V XUL736100.000000I Renesas晶振 MULTIMKT-TIMING XU 100 MHz LVDS 3.3V XUL536156.250000I Renesas晶振 MULTIMKT-TIMING XU 156.25 MHz LVDS 3.3V XUL736150.000000I Renesas晶振 MULTIMKT-TIMING XU 150 MHz LVDS 3.3V XK03L106L212L425I Renesas晶振 PROXO 2 1.8 X 1.4MM 55FS PROGRAM - - - - XK03L156L312L625I Renesas晶振 PROXO 2 1.8 X 1.4MM 55FS PROGRAM - - - - XK03R156R312R625I Renesas晶振 PROXO 2 1.8 X 1.4MM 55FS PROGRAM - - - - XK01H050H100H125I Renesas晶振 PROXO 2 1.8 X 1.4MM 55FS PROGRAM - - - - XK03L161L322L644I Renesas晶振 PROXO 2 1.8 X 1.4MM 55FS PROGRAM - - - - XK13R156R312R625I Renesas晶振 PROXO 2 2.0 X 1.6MM 55FS PROGRAM - - - - XK13L161L322L644I Renesas晶振 PROXO 2 2.0 X 1.6MM 55FS PROGRAM - - - - XK13L106L212L425I Renesas晶振 PROXO 2 2.0 X 1.6MM 55FS PROGRAM - - - - XK11H050H100H125I Renesas晶振 PROXO 2 2.0 X 1.6MM 55FS PROGRAM - - - - XK13L156L312L625I Renesas晶振 PROXO 2 2.0 X 1.6MM 55FS PROGRAM - - - - XK23R156R312R625I Renesas晶振 PROXO 2 2.5 X 2.0MM 55FS PROGRAM - - - - XK23L156L312L625I Renesas晶振 PROXO 2 2.5 X 2.0MM 55FS PROGRAM - - - - XK21H050H100H125I Renesas晶振 PROXO 2 2.5 X 2.0MM 55FS PROGRAM - - - - XK23L161L322L644I Renesas晶振 PROXO 2 2.5 X 2.0MM 55FS PROGRAM - - - - XK23L106L212L425I Renesas晶振 PROXO 2 2.5 X 2.0MM 55FS PROGRAM - - - - XK31H050H100H125I Renesas晶振 PROXO 2 3.2 X 2.5MM 55FS PROGRAM - - - - XK33L161L322L644I Renesas晶振 PROXO 2 3.2 X 2.5MM 55FS PROGRAM - - - - XK33L106L212L425I Renesas晶振 PROXO 2 3.2 X 2.5MM 55FS PROGRAM - - - - XK33L156L312L625I Renesas晶振 PROXO 2 3.2 X 2.5MM 55FS PROGRAM - - - - XK33R156R312R625I Renesas晶振 PROXO 2 3.2 X 2.5MM 55FS PROGRAM - - - - XPP336100.000000I Renesas晶振 CLCC 3.20X2.50X0.95 MM, 2.10MM P XP 100 MHz LVPECL 3.3V XFL235837.500000K Renesas晶振 DFN 2.00X2.50X1.00 MM, 0.40MM PI XF 837.5 MHz LVDS 3.3V
瑞萨基于现有IPD器件推出"电子保险丝配电箱"解决方案。利用小型IPD取代电箱中的传统保险丝,并将保险丝特性编程至微控制器中。开发人员可优化线束,并通过电流监测提高可靠性。该解决方案是瑞萨"成功产品组合"的一部分。瑞萨"成功产品组合"将相互兼容的瑞萨有源振荡器器件优化并组合,实现无缝协作,以降低用户设计风险并缩短上市时间。瑞萨现已基于其产品阵容中的各类产品,推出超过300款"成功产品组合"。
关于瑞萨电子
瑞萨电子,科技让生活更轻松,致力于打造更安全、更智能、可持续发展的未来。作为全球微控制器供应商,瑞萨电子融合了在嵌入式处理、模拟、电源及连接方面的专业知识,提供完整的半导体解决方案。成功产品组合加速汽车、工业、基础设施及物联网应用上市,赋能数十亿联网智能设备改善人们的工作和生活方式。
Renesas delivers trusted embedded design innovation with complete semiconductor solutions that enable billions of connected, intelligent devices to enhance the way people work and live. Our mission is to help develop a safer, healthier, greener, and smarter world by bringing technology into four segments: Automotive, Industrial, Infrastructure, and IoT (Internet of Things).
In 2021, Renesas completed its acquisition of Dialog, expanding its footprint in Europe. With Intersil, IDT and Dialog now in the fold, Renesas enters a new era as a truly cosmopolitan company with a progressive mindset and modern vision to lead the industry.
