频率：16MHz
尺寸：2.0*1.6mm
FC1BSCCEM16.0-T3,石英晶体谐振器,高频晶振,福克斯电子,四脚贴片晶振,石英晶振,高频晶振,福克斯进口晶振,FOX超小型晶振,6G信号发射塔晶振,福克斯晶振深圳授权代理商,福克斯石英晶振,耐高温特性使得它能够在-40°C至85°C的环境下能够平稳的运行,负载电容:10pF,频率:16MHz,频率偏差:±30ppm,频率容差:±30ppm,型号:FC1BS,
FC1BSCCEM16.0-T3,石英晶体谐振器,高频晶振,福克斯电子
| 原厂编码 | FC1BSCCEM16.0-T3 |
| 频率 | 16MHz |
| 厂家 | FOX晶振 |
| 型号 | FC1BS |
| 频率偏差 | ±30ppm |
| 负载电容 | 10pF |
| 工作温度 | -40°C至85°C |
| 尺寸 | 2.0*1.6mm |
FC1BSCCEM16.0-T3,石英晶体谐振器,高频晶振,福克斯电子
| 编码 | 品牌 | 型号 | 频率 | 频率偏差 | 频率容差 | 负载电容 |
| FC3BACAGI16.0-T3 | Fox crystal | FC3BA | 16 MHz | ±100ppm | ±30ppm | 12 pF |
| FC3BACALI16.0-T3 | Fox crystal | FC3BA | 16 MHz | ±100ppm | ±30ppm | 18 pF |
| FC3BACBDI16.0-T3 | Fox crystal | FC3BA | 16 MHz | ±50ppm | ±30ppm | 8 pF |
| FC3BACCGM20.0-T3 | Fox crystal | FC3BA | 20 MHz | ±30ppm | ±30ppm | 12 pF |
| FC3BACCLP12.0-T3 | Fox crystal | FC3BA | 12 MHz | ±30ppm | ±30ppm | 18 pF |
| FC3BAEBDI12.0-T1 | Fox crystal | FC3BA | 12 MHz | ±50ppm | ±20ppm | 8 pF |
| FC3BAEBDI16.0-T1 | Fox crystal | FC3BA | 16 MHz | ±50ppm | ±20ppm | 8 pF |
| FC3BAEBDI20.0-T1 | Fox crystal | FC3BA | 20 MHz | ±50ppm | ±20ppm | 8 pF |
| FC3BAEBDI24.0-T1 | Fox crystal | FC3BA | 24 MHz | ±50ppm | ±20ppm | 8 pF |
| FC3BAEBDI25.0-T1 | Fox crystal | FC3BA | 25 MHz | ±50ppm | ±20ppm | 8 pF |
| FC3BAEBDI40.0-T1 | Fox crystal | FC3BA | 40 MHz | ±50ppm | ±20ppm | 8 pF |
| FC3BQBBME12.0-T3 | Fox crystal | FC3BQ | 12 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBME16.0-T1 | Fox crystal | FC3BQ | 16 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBME24.0-T1 | Fox crystal | FC3BQ | 24 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBME25.0-T1 | Fox crystal | FC3BQ | 25 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBME25.0-T3 | Fox crystal | FC3BQ | 25 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBME27.0-T1 | Fox crystal | FC3BQ | 27 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBMM12.0-T1 | Fox crystal | FC3BQ | 12 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBMM12.0-T3 | Fox crystal | FC3BQ | 12 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBMM24.0-T1 | Fox crystal | FC3BQ | 24 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBMM24.0-T3 | Fox crystal | FC3BQ | 24 MHz | ±50ppm | ±50ppm | 20 pF |
| FC3BQBBMM25.0-T1 | Fox crystal | FC3BQ | 25 MHz | ±50ppm | ±50ppm | 20 pF |
深圳市火运电子有限公司
服务热线：86-0755-29952551
手机联系：136-3294-3514
Q Q联系：969080538
邮 箱：longhusz@163.com
地 址：深圳市宝安区新安街道安乐社区二街
贴片晶振本身体积小,超薄型石英晶体谐振器,特别适用于有目前高速发展的高端电子数码产品,因为晶振本身小型化需求的市场领域,小型,薄型是对应陶瓷谐振器（偏差大）和普通的石英晶体谐振器（偏差小）的中间领域的一种性价比较出色的产品.产品广泛用于笔记本电脑,无线电话,卫星导航HDD, SSD, USB, Blu-ray等用途,符合无铅焊接的高温回流焊曲线特性.
